Stainless Braided Hose

(Code: 47 Braided Hos1-8 32)
Shopping Satisfaction
Stainless Braided Hose Size : 1/8" 3.2 mm Internal Diameter (7.5mm External)
Add to cart
Discount on quantity

  • Greatly outlasts ordinary hose
  • Precise fit - no leakage
  • Protective braid greatly reduces possibility of breakdown through chafing
  • Stainless reflective weave helps prevent vapourisation problems on fuel line and boiling issues when used for brake and water lines.
  • This hose was originally marketed as a hosed upgrade since the 1960s under the Smiths Petroflex brand.
  • High performance 304 grade stainless - the best available
  • Suitable for petrol, diesel, oil, water etc, suitable for all modern fuels, Ethanol (E10-E85) compatible
  • Nitrided rubber internal section (with internal fabric reinforcement, unlike some cheap imported versions on the market) on all sizes except 1/8" which is nylon reinforced as suitable for high pressure brake & clutch line.

Available in a range of size of internal diameter:

  • 1/8" (3.2mm) is used for brake and clutch line. Swaged fittings must be used in this high pressure application. Although somewhat over-engineered for the purpose we have also seen this hose used for washers, dizzy vacuum hose and other micro bore applications to good effect.
  • 1/4" (6mm) or 5/16" (8mm) is used for most classic car fuel lines
  • 3/8" (10mm) is used on most classic Jaguars & the vast majority of American classics
  • 1/2" (12mm) is usually employed for water and oil line hose
  • Use with MagnaClamps or Rubber End Caps, or swaged fittings (swaged fittings must be used for brake line)

Sold per metre - eg if 10 are ordered you will receive a continuous length of 10m; maximum continuous length 30.

Cut to your lengths required with a serrated edge, eg hacksaw or kitchen bread knife.
Code Stainless Braided Hose Size  Price
47 Braided Hos1-8 32  1/8" 3.2 mm Internal Diameter (7.5mm External)  4.68 Details Buy
47 Braided Hose1-4 6  1/4" 6mm Internal Diameter (13.3mm External)  8.28 Details Buy
47 Braided Hos5-16 8  5/16" 8mm Internal Diameter (15.3mm External)  9.48 Details Buy
47 Braided Hos3-8 10  3/8" 10mm Internal Diameter (15.6mm External)  9.80 Details Buy
47 Braided Hos1-2 12  1/2" 12mm Internal Diameter (22mm External)  13.18 Details Buy
Customer reviews
Shopping Satisfaction
Stainless Braided Hose Size : 1/4" 6mm Internal Diameter (13.3mm External)
Can be difficult to achieve tidy ends, but good value when bought by the metre.
